Test reporting is one the important activity in quality assurance. It doesn’t matter whether you are a manual tester or automation tester, you must implement logging as well as reporting activities in your Automation framework. Extent reports give the seamless environment to implement test report generation in the Selenium project.
Extent reports efficiently support HTML reporting. It gives a broader view of the end results. Let’s discuss some of the advantages of using Extent Reports for test reporting in Selenium WebDriver.
Don’t Miss: How to set up Jenkins connection in Maven project for Selenium?
Advantages of reporting through Extent Reports:
- It shows coverage in percentage
- Pass – Failed report comes in pie chart format
- A tabular format to display Pass, Fail and Skipped test step
- Test environment details appear automatically in the Test report
- Total tests and Total steps appear in the report
- Total time taken for the current run as well as total time taken for the overall run appears in the report along with Start and end time count
- Tests are configured and customized as per the choice of the test engineer/developer
- Easy to implement this reporting in the Automation framework
How to set up Extent Reports in IDE?
Firstly you need to add the library files of the Extent Reports. You can do it by uploading the external JARs to your project. Click here to download the JAR file.
If you are using Maven then add its dependencies to the pom.xml file.
<dependency>
<groupId>com.relevantcodes</groupId>
<artifactId>extentreports</artifactId>
<version>2.40.2</version>
</dependency>
How to implement Extent Reports in Selenium Automation framework?
As I claim above (in the title) that you only need 5 lines of code to implement the Extent reports, which is true as Sun rises in the east.
Here are the codes which you need to implement:
Starts with-
ExtentReports report = new ExtentReports(reportPath+".html", false);
ExtentTest test = report.startTest("Extent Report Example Project");
Ends with-
report.endTest(test);
report.flush();
report.close();
As you see above, you just need these five lines of code to implement Extent reports in your test automation framework. Let me explain the above code.
Step# 1: We create the instance of ExtentReports class and we pass arguments as path and file name with extension .html. As you see above, I have given the link to the path followed by file name as the current class name with .html as the extension.
Step# 2: Once the instance of ExtentReports created and path passed as the argument then we need to create the instance of ExtentTest. It holds the method which initiates and end the tests Along with the Log status as PASS, FAIL, SKIP, ERROR, FAIL, FATAL and WARNING.
Step# 3: You need to implement the log status with the help of the instance of ExtentTest. You can implement it wherever you are asserting any condition as pass or fail. We will see it further in this tutorial.
Step# 4: At the end, you need to end the test along with flushing and closing of the report. It will help you to write the reporting to the designated file name.
Let’s discuss the implementation of Extent Reports in the execution of the test.
Scenario: We are taking a scenario in which the driver will open the URL and it will capture the title at the home page. Now our task is to assert the title through the if-else statement. If the title contains the expected keyword, then Extent Reports should print this as pass. Similarly, if the title does not contain the keyword then Extent reports should print fail in the report generated.
Let’s have a look at the sample code:
Sample Code:
package com.inviul.selenium.project;
import org.testng.annotations.Test;
import com.relevantcodes.extentreports.ExtentReports;
import com.relevantcodes.extentreports.ExtentTest;
import com.relevantcodes.extentreports.LogStatus;
import org.testng.annotations.BeforeMethod;
import java.io.File;
import java.util.concurrent.TimeUnit;
import org.openqa.selenium.WebDriver;
import org.openqa.selenium.chrome.ChromeDriver;
import org.testng.annotations.AfterMethod;
public class ExtentReportExample {
WebDriver driver = null;
public ExtentReports report;
public ExtentTest test;
String reportPath = new File("").getAbsolutePath().toString().trim()+"/Reports/";
@BeforeMethod
public void beforeMethod() {
System.setProperty("webdriver.chrome.driver", "C:\\Selenium\\chromedriver.exe");
driver = new ChromeDriver();
//***********Extent Report Implementation***********
report = new ExtentReports(reportPath+this.getClass().getSimpleName()+".html", false);
//Starting the test case for reporting
test = report.startTest("Extent Report Example Project");
//***********Extent Report Implementation***********
}
@Test
public void extentReport() {
driver.get("http://www.inviul.com/");
driver.manage().timeouts().implicitlyWait(10, TimeUnit.SECONDS);
driver.manage().window().maximize();
String title = driver.getTitle();
//Setting Pass Failure Log
if(title.contains("Avinash")){
System.out.println(title);
test.log(LogStatus.PASS, "Validate title matched for the web page", "Title matched");
}else{
test.log(LogStatus.FAIL, "Validate title matched for the web page", "Title didn't match");
}
}
@AfterMethod
public void afterMethod() {
driver.close();
driver.quit();
//Closing the report
report.endTest(test);
report.flush();
report.close();
}
}
In the above code, you see the creation of the instance of both ExtentReports class and ExtentTest class are done inside @BeforeMethod annotation. Further, logging is done inside the @Test annotation. Ultimately, report closing and flushing are handled inside the @AfterMethod annotation.
Tip:
One thing you should have noticed that there is a Boolean as another argument in ExtentReports() class. Right?
So, you may ask its significance here.
If we keep false then the single report will hold all the logs, otherwise on setting it to true will lead to the generation of multiple report file for every pass-fail status.
This is all about implementation of Extent Reports in your Selenium project. If you have any queries, please share in the comment below and join our Facebook group for the latest updates.
Hi Avinash,
Thanks for sharing useful article on extent report. I have implemented extent report feature in my testng framework. All the steps are getting logged in the html report for the test cases. But html report is displayed as plain text. I dont see tabs and pie chart. Could you please help me.
Regards,
Sudha
Hi Sudha,
It might be an issue with your browser loading. Try in a different browser. You can mail me the details if still error exists.
Hi Avinash,
I have implemented extent report in cucumber framework. But in parallel execution report for the last executed test case, it is showing as unknown in test name and not generating report for last executed case(Working fine for sequential execution). Could you please help in resolving this.
Please let me know if any pre conditions I need to follow while parallel test execution.
Thanks in advance.
Regards,
Balireddy
Hi Avinash,
I have implemented extent report in cucumber framework. But in parallel execution report for the last executed test case, it is showing as unknown in test name and not generating report for last executed case(Working fine for sequential execution). Could you please help in resolving this.
Please let me know if any pre conditions I need to follow while parallel test execution.
Thanks in advance.
Regards,
Balireddy
Please mail me your code. I will review it and can give you solution.
hey avinash,
i tried this. it is working fine. but i want to check in real time project. how can i do that. plz provide some sample project
Please download my project from GitHub.
Hi Avinash,
I have a problem, some test cases are showing as warning while executing in suite file but test cases are passed if i run them individually.
Please share more details.
Hi Avinash,
Thanks for sharing the ExtentReport implementation details. I have successfully implemented in my framework. One thing I wanted to check, is there any way to change the title of Extent Report. In my case, its showing as ‘ExtentReports 2.0’? I want to change/customize it according to my requirement.
